DJI RS 5 Gimbal Stabilizer
DJI RS 5 Gimbal Stabilizer
DJI RS 5 Gimbal Stabilizer
  • Out of stock

DJI RS 5 Gimbal Stabilizer

SKU: DJI-RS500

170.000 KD Shipping calculated at checkout.
Warranty

1-Year Warranty

Quantity

DJI RS 5 Gimbal Stabilizer

Quick Highlights

  • 3kg Tested Payload For mirrorless camera and lens setups
  • 5th-Gen Stabilization Smooth footage while walking and tracking
  • 50% More Motor Torque Versus the previous generation
  • 2nd-Gen Auto Axis Locks Faster setup and transport
  • Native Vertical Shooting No extra accessories needed
  • Fine-Tuning Knobs Precise camera balancing
  • 14-Hour Standby With the BG33 battery grip
  • 1-Hour Fast Charging With a 65W USB-C PD charger
  • Tracking-Ready Supports the optional RS Enhanced Intelligent Tracking Module

About Product

Description

Move freely. Keep every shot under control.

The DJI RS 5 Gimbal Stabilizer brings advanced camera stabilization to professional creators, videographers and filmmakers who need reliable performance in a portable system.

Equipped with DJI's fifth-generation RS stabilization algorithm, the RS 5 delivers smooth footage during walking, tracking and dynamic camera movements. Improved motor torque provides additional stabilization capability for compatible mirrorless camera and lens combinations weighing up to 3kg.

Balancing is easier with fine-tuning knobs and Teflon-enhanced axis movement, while second-generation automated axis locks simplify setup and transportation. The RS 5 also supports native vertical shooting, making it convenient to switch between traditional video and social-first content.

For more advanced subject tracking, the optional RS Enhanced Intelligent Tracking Module enables touchscreen subject selection and automated tracking of supported subjects. An optional electronic briefcase handle expands low-angle filming and gimbal control options.

With approximately 14 hours of maximum standby time under specified conditions and fast charging through a compatible 65W USB-C PD charger, the DJI RS 5 is built to support demanding creative workflows.

Specification
  • Model Name: DJI RS 5
  • Product Type: 3-Axis Camera Gimbal Stabilizer
  • Tested Payload: 3.0kg
  • Stabilization System: Fifth-Generation RS Stabilization Algorithm
  • Motor Torque Improvement: 50% Higher Peak Torque Compared with Previous Generation
  • Axis Locks: Second-Generation Automated Axis Locks
  • Vertical Shooting: Supported
  • Maximum Controlled Pan Speed: 360°/s
  • Maximum Controlled Tilt Speed: 360°/s
  • Maximum Controlled Roll Speed: 360°/s
  • Pan Mechanical Range: 360° Continuous Rotation
  • Roll Mechanical Range: -95° to +240°
  • Tilt Mechanical Range: -112° to +214°
  • Battery Grip Model: BHX715-2150-15.48
  • Battery Type: LiPo 4S
  • Battery Capacity: 2150mAh
  • Battery Energy: 33.29Wh
  • Battery Voltage: 11.2V–17.8V
  • USB Input: 5V/3A, 9V/3A, 12V/3A, 15V/3A, 20V/3A
  • Maximum Standby Time: Approximately 14 Hours with DJI RS BG33 Battery Grip Under Test Conditions
  • Charging Time: Approximately 1 Hour with Compatible 65W PD Charger Under Test Conditions
  • Recommended Charging Temperature: 5°C to 40°C
  • Bluetooth Version: 5.0
  • Wireless Operating Frequency: 2.4000–2.4835GHz
  • Bluetooth Transmitter Power: Less Than 8dBm
  • Charging Port: USB-C
  • Camera Control Port: USB-C
  • Multifunctional Port: USB-C
  • Accessory Interfaces: RSA/NATO Ports, 1/4"-20 Mounting Hole, Cold Shoe
  • Ronin App Requirements: iOS 14.0 or Above; Android 9.0 or Above
  • Gimbal Weight: Approximately 1193g Including Quick-Release Plates and Screws
  • Grip Weight: Approximately 274g
  • Quick-Open Tripod Weight: Approximately 149g
  • Quick-Release Plates Weight: Approximately 96g Including Screws
  • Folded Dimensions: 247.4 × 115.7 × 258.7mm, Excluding Camera, Grip and Tripod
  • Unfolded Dimensions: 223.2 × 192.2 × 418.8mm, Including Grip, Excluding Camera and Tripod
  • Operating Temperature: -20°C to 45°C
  • Optional Intelligent Tracking Module Weight: Approximately 19g
  • Optional Intelligent Tracking Module Dimensions: 36.3 × 17.5 × 38.2mm
  • Optional Tracking Distance: 0.5–10m
  • Optional Tracking Module Operating Temperature: -10°C to 45°C

Key Benefits
  • Smooth cinematic movement: Advanced stabilization supports handheld tracking, movement and creative camera shots.
  • More precise balancing: Fine-tuning knobs make small adjustments easier during setup.
  • Switch shooting orientation: Native vertical shooting supports content created for mobile-first platforms.
  • Travel more efficiently: Automated axis locks make packing and transporting the gimbal more convenient.
  • Expand your creative controls: Optional tracking and briefcase-handle accessories support more shooting techniques.
  • Fast power replenishment: Compatible PD charging helps reduce battery downtime.
