  • In stock

Bluetti Charger 1 Alternator Charger 560W

SKU: CH1

89.000 KD Shipping calculated at checkout.
Warranty

2-Year Warranty

Quantity

Bluetti Charger 1 Alternator Charger 560W

Quick Highlights

  • 560W Maximum Charging Output For compatible portable power stations
  • Up to 6× Faster Charging More than traditional vehicle cigarette-lighter charging under manufacturer test conditions
  • Compatible with 12V and 24V Vehicle electrical systems
  • Adjustable Output Voltage through the BLUETTI app
  • Bluetooth Connectivity For charging monitoring and configuration
  • Protections Built-in short-circuit, reverse-polarity, undervoltage and overtemperature protection
  • Active Fan Cooling Automatic on/off functionality

About Product

Description

Turn every drive into charging time.

The BLUETTI Charger 1 560W Alternator Charger lets you recharge compatible portable power stations directly from your vehicle's electrical system while driving, without relying on a conventional cigarette-lighter outlet.

Delivering up to 560W, Charger 1 provides significantly faster charging than traditional vehicle charging methods. Its adjustable DC output supports a wide range of compatible BLUETTI power stations and other supported portable power systems, provided the correct cables and input settings are used.

Through Bluetooth and the BLUETTI app, you can monitor charging status and adjust output voltage to suit your connected power station. Automatic voltage monitoring helps prevent unnecessary vehicle battery discharge, while active cooling and multiple circuit protections support reliable operation.

Designed for road trips, camping, overlanding and mobile power setups, Charger 1 helps make the most of your time on the road.

Specification
  • Model Name: Charger 1
  • Product Type: Alternator Charger / DC-DC Charger
  • Maximum Output Power: 560W
  • Default Output Voltage: 27V
  • Output Voltage Range with 12V Battery: 15.0V–56.0V
  • Output Voltage Range with 24V Battery: 27.0V–56.0V
  • Output Current: 10A
  • Input Voltage: 12V–14V / 22.5V–28V
  • Input Current: 50A (12V) / 25A (24V)
  • Charging Application: Compatible Portable Power Stations with Supported DC Charging Inputs
  • Output Voltage Adjustment: BLUETTI App
  • App Connectivity: Bluetooth
  • Cooling System: Active Fan Cooling
  • Automatic Start/Stop: Supported
  • Protection Features: Short Circuit, Reverse Connection, Undervoltage, Overtemperature
  • Optional Surge Protection: 60A Circuit Breaker
  • Ingress Protection Rating: IP20
  • Maximum Operating Noise: 50dB
  • Operating Temperature: -20°C to 60°C
  • Dimensions: 145 × 110 × 60mm
  • Net Weight: Approximately 1.2kg

Key Benefits
  • Recharge while driving: Use your vehicle's electrical system to replenish a compatible power station during your journey.
  • Reduce charging downtime: Up to 560W output provides faster charging than standard vehicle sockets.
  • Adjust power intelligently: Configure output voltage through the BLUETTI app to suit supported devices.
  • Protect your vehicle battery: Automatic start/stop monitoring helps prevent unnecessary discharge.
  • Built for travel: A compact design and integrated cooling make it suitable for mobile power installations.
